YONGLE 8874 PVC Automotive Wire Harness Tape, -25°C to 105°C Temperature Rated
| application | Wire harness tape |
| carrier | PVC |
| caliper | 100μm |
| construction | Single-side Tape |
| compliace | RoHS, REACH |
| performace_feature | Low VOC/Odor, Flame Resistant, Solvent Resistant |
| heat_resistance | 105℃ |
YONGLE 8874 Soft PVC Automotive Wire Harness Tape
YONGEL 8874 Harness Wrap Tape is made from soft PVC film coated with a rubber-based adhesive. It is designed for permanent wrapping on wiring harnesses and can be applied by hand or machine.
The tape provides a highly conformable wrapping solution with pressure-sensitive adhesion, flame-resistant performance and controlled, even unwind.
What Makes 8874 Different
8874 uses a soft PVC film carrier combined with a rubber-based adhesive system. This construction is designed for permanent wiring harness wrapping where flexibility, conformability and controlled tape handling are required.
The product is available in several standard widths, lengths and colors. Other sizes and colors are available on request.
Key Features
Soft PVC film carrier
Rubber-based adhesive
Highly conformable
Pressure sensitive
Flame resistant
Controlled, even unwind
Hand and machine applicable
RoHS & REACH
Technical Advantages for Wire Harness Wrapping
The soft PVC film provides a flexible carrier for wrapping around wiring harnesses and cable bundles. The rubber-based adhesive provides pressure-sensitive adhesion during the wrapping process.
The controlled, even unwind characteristic supports consistent tape handling during manual and machine application.
Applications in Automotive & Industrial Systems
Trucks
Cars
Recreational vehicles
Construction equipment
Farm implements
Aircraft
Aerospace
Electronic assemblies
Wiring Harness Wrapping Applications
8874 is recommended for permanent wrapping on wiring harnesses used in vehicles, equipment and electronic assemblies.
The product is suitable for applications where a soft PVC carrier, pressure-sensitive adhesion and controlled unwind are required.
Product Summary
8874 Harness Wrap Tape uses a soft PVC film carrier coated with a rubber-based adhesive. It provides a highly conformable, pressure-sensitive and flame-resistant tape solution for permanent wiring harness wrapping.
The standard product is available in multiple widths, lengths and colors, with other sizes and colors available on request.
Technical Data
| Property | Value | Unit | Test Method |
|---|---|---|---|
| Total Thickness | 0.100 ± 0.02 | mm | EN 1942 |
| Tensile Strength | >16 | N/cm | ISO 29864 |
| Elongation at Break | >180 | % | ISO 29864 |
| Adhesion Strength to Steel | >1.5 | N/cm | ISO 29862 |
| Adhesion Strength to Backing | >1.5 | N/cm | ISO 29862 |
| Unwind Force | 1.5~4.0 | N/cm | EN 1944 |
| Flammability | B (Self-extinguishing) | — | GMW 16740 / LV 312 |
| Breakdown Voltage | 4.5 | kV | ASTM D1000 |
| Temperature Rating | -25~105 | °C | GMW 16740 / LV 312 |
The above are typical values and should not be used in writing specifications. Customer is responsible to ensure the product meets intended application requirements before approval for use.
Standard Sizes & Colors
Length: 30m, 53.7m
Width: 9mm, 12mm, 19mm, 32mm
Core ID: 38mm
Colors: Black, White, Gray, Dark Orange, Yellow
Other sizes and colors are available on request.
Storage & Shelf Life
The shelf life of the product is five years when stored at 20–30°C, maximum 65% relative humidity, out of direct sunlight and in original packaging.
